Payload
20 KG
Maximized Reach
1800 mm
Consistent Accuracy
±0.02 mm
Enhanced Speed
Max 3 m/s
Safety Features
Pld Cat. 3 / SIL 2
Delta D-Bot Weight
101 KG
| Axis | Working Angles D-Bot 6 / 8 / 10 / 16 / 20 / 30 |
Maximum Speed (°/s) | |||
|---|---|---|---|---|---|
| D-Bot 6 | D-Bot 8 & 10 | D-Bot 16 | D-Bot 20 & 30 | ||
| A1 | ± 180° | 200°/s | 180°/s | 120°/s | 120°/s |
| A2 | ± 180° | 200°/s | 180°/s | 120°/s | 120°/s |
| A3 | ± 120° | 200°/s | 180°/s | 200°/s | 120°/s |
| A4 | ± 150° | 200°/s | 180°/s | 200°/s | 120°/s |
| A5 | ± 180° | 230°/s | 220°/s | 200°/s | 200°/s |
| A6 | ± 180° | 230°/s | 220°/s | 200°/s | 200°/s |
