OnRobot

VGP 30

Powerful electric vacuum gripper for heavy payload material handling. The VGP30 supports 1–20 cups, offers modular flexibility, and runs on 24 V without external vacuum systems. Integrates easily with Delta cobots and enables quick setup with intelligent control.

  • High payload
  • Flexible & modular, 1–20 cups
  • Lightweight compact design
  • Built‑in control adjusts flow automatically
Target audience
Target Audience
  • Packaging and material‑handling tasks
Use case
Use Case
  • Material handling
  • Palletizing
Specifications
Category
VGP30
Overview
Payload (kg) 30
Weight (kg) 3,1
Dimension (mm) 390 x 240 x 62.10
Vacuum pump Compressed air input
Vacuum Cups 1–20
Compressed air flow (L/min) 440
Compressed air pressure (bar) 7
Performance
Min. Operating Temp. (°C) 0
Max. Operating Temp. (°C) 50
Vacuum (bar) -0.05 – -0.607
Air flow in total (L/min) 440
Air Flow each channel (L/min) 220
Releasing time (ms) 80
Gripping Time (ms) 150
Noise Level (dB(A)) 59
Interface
Supply voltage 24
Max. Current (mA) 2000
Communication —
Mounting Interface —
Properties
IP classification IP54
Dust filter Integrated 50µm, field replaceable

Download

Download PDF
OnRobot VGP30
Download the OnRobot VGP30 Datasheet here
Get a Quote

Best paired with

DC 06DC 06
DC 08DC 08
DC 10DC 10
DC 16DC 16
DC 20DC 20
DC 30DC 30
OnRobot

OnRobot delivers electric grippers, vacuum grippers, and application kits that simplify automation tasks like packaging and palletizing. Their solutions integrate easily with Delta cobots and help manufacturers of all sizes deploy quickly.
