MOOVair 01 Wireless Charging System​

Charge Wisely, Charge Wirelessly
The 1 kW Wireless Charging System is a revolutionary, low maintenance, high efficiency product ideal for charging batteries in industrial electric vehicles and AGVs. The sealed electronics and contactless power transfer are especially suitable for use in highly polluted or wet environments.

Product Introduction

Technology
Delta has advanced the industrial wireless charging technology through a third-party licensing agreement, leveraging own extensive expertise in power supplies to introduce the cutting-edge MOOVair Wireless Charging System Series. It consists of a primary unit for AC connection and a secondary unit for connection to the vehicle battery. Delta MOOVair 01 Wireless Charging System initiates charging automatically and boasts wall plug to battery efficiency at up to 93%. The built-in CANopen and Ethernet connectivity enables integration with smart warehouse or factory management systems for improved visibility of the charging data. The Delta MOOVair 01  Wireless Charging System is the must-have to smartify your industrial vehicles in the Industry 4.0 era.
Features & Benefits

  • Easy integration into the vehicle:  MOOVair 01 Wireless Charging System charges any battery type incl. Li-ion of 24 V/ 36V/ 48V. GUI (graphical user interface) available to support early integration.
  • No maintenance downtime. No connector wear and tear thus eliminating the need for maintenance.
  • Exceptional efficiency. Charges just as fast and efficient as your wired charger. MOOVair 01 achieves above 93% efficiency wall socket to battery within a gap of up to 20 mm.
  • Easy installation in the facility for unmanned 24/7 operation: Due to compact size MOOVair wireless charging stations are easy to install for in-process and opportunity charging without altering the facility. By demand chargers can be put in parallel to increase the power level.
  • Flexible charging capability with consistent 1000W power delivery. Multiple vehicles equipped with 24V, 36V, and 48V batteries can utilize a single charging base, ensuring a consistent delivery of 1000W of power with unwavering reliability.
  • Enhanced vehicle operability and control. Automated charging based on customized preconfigured parameters or vehicle-controlled via CAN bus.
  • Reliable performance in challenging environments: IP 65 ensuring continuous operation even in harsh and polluted environments.
  • Safe operation. No risk of sparks or arcing due to absence of wires and connectors. Electromagnetic field exposure as low as common household devices like induction cooktop or microwaves. Finally, all products are CE, UL (MET), FCC certified herewith meeting the highest industrial safety standards.

Applications

  • AGVs & AMRs
  • Pallet jacks
  • Utility vehicles
  • Service robots
  • Agricultural robots
  • Industrial robots
  • UV disinfection robots
Specifications
Download

1kW Wireless Charging System EU DoC EN/750KB

1kW Wireless Charging System_Leaflet EN V3.0_Oct.2024
